Input & Output
- Input voltage:400V AC
- Input frequency:50Hz
- Output voltage:400V AC
- Max. output power:22KW
- Max. output current:32A
- Charging interface type:IEC 62196-2, Type ll
Protection
- Over voltage protection:Yes
- Under voltage protection:Yes
- Over load protection:Yes
- Short circuit protection:Yes
- Earth leakage protection:Yes
- Ground protection:Yes
- Over-temp protection:Yes
- Lightning protection:Yes
EVA-22S AC Charging Station
(Three phase - 22kW EV Charger)
COMPACT DESIGN
Attractive appearance, 4.3‘’ LCD screen, A4 print paper size, simple but elegant.
FULL PROTECTION
Full electrical protection, over/under temperature protection, etc.
STABLE
IP65 protection grade, capable
for harsh environment,
salt-mist condition
INTELLIGENT
Emergency stop,
4G/ethernet/Wifi/APP
monitoring, RFID/QR/-
Bluetooth payment
support.
EUROPEAN STANDARD
OCCP v1.6 standard open
communication protocol,
IEC62196-2 type 2 connector
EASY TO INSTALL
Wall-mounting or
pole-mounting optional.
Designed to meet your specific needs...
| Standard Price (LAN/Wall Mounting) | Included |
| Charging Socket | Included |
| Monitoring/WiFi | Included |
| RCD/TYPE A | Included |
| RFID | Included |
| RFID card | Included |
| RFID card (additional cards) | Optional |
| LCD screen | Optional |
| Charging Gun (3m) | Optional |
| Monitoring/4G | Optional |
| Mounting/Pole | Optional |
| Sensor + automatic power regulation | Optional |
| Car Detection | Optional |
Environment
| IP grade | IP65 |
| Operation temperature | -30°C ~ +55°C |
| Operation Humidity | 5% ~ 95% without condensation |
| Operation attitude | <2000m |
| Cooling methods | Natural air cooling |
| Standby power consumption | <8W |
Mechanical
| Dimension（L*W*H） | 420*270*135mm |
| Weight | <16KG |
Mounting Accessories
| Wall-mounting bracket⁄ | *Pole dimension& weight: |
| Ground-mounting pole | 200mm*1200mm*180mm(W*H*D), 8.5kg |
